Material cutting is performed on the machine TruLaser 3030 fiber
Material cutting is performed on the most modern computer controlled laser machine with the type reference TruLaser 3030 fiber.
|
|
|
TruLaser 3030 fiber is impressive with its high flexibility and reliability. It efficiently cuts with air mainly structural steel with all possible tin plate thickness.
Solid laser TruDisk 3001 enables tooling of ferrous metals and except that are its advantages in productivity of tooling of the thin tin plate. Minimal side times are ensured by the verified functions as e.g. automatic nozzle changer.
|
Technical specification
TruLaser 3030 fiber
| Laser machine TRUMPF with performance 3000W |
| Size of working table (width x length) |
1500 x 3000mm |
Maximum thickness of the material
| Structural steel |
20mm |
| Premium steel |
15mm |
| Aluminium |
15mm |
| Copper |
6mm |
| Brass |
6mm |
Possibilities of cutting
| Using oxygen |
yes |
| Using nitrogen |
yes |
| Using air |
yes |
Presentation video Trulaser 3030 fiber
Advantages of Trulaser 3030 fiber
- Possibility of cutting the tin plate with thickness up to do 20mm
- Enlarged portfolio of the materials: cutting copper and brass using TPUMPF cutting parameters
- High productivity in the area of thin tip plates thanks to solid laser TruDisk
- Productivity advantages in the area of thin tin plates
- Troubfree tooling of the tin plate coated with foil without previous evaporation
- Minimal side times thanks to automatic nozzle changer and strategy of one laser head
- Highest energy efficiency
General conditions
- Quality of cutting surface is guaranteed according to STN EN ISO 9013, grade I., local defects of the cutting surface when assesing are not regarded according this norm
- Documentation for tooling of cutting plans are processed according specified dimension in simple shapes, or drawing documentation of the cut shapes DXF, DWG sent by e-mail, fax or brought personally
- Archiving of the drawing documetation
- Standard term of delivery from the material, that is on stock is 3 to 10 working days after order confirmation, express orders are surcharged. Delivery parity EXW producer or after agreement it is possible also delivery with the transport of MOLPIR, s.r.o. to the agreed destination
- Cutting of the cuts into materials delivered by the customer
- Possibility of cutting holes until 0.7mm x thickness depending on the thickness of the material
- Labeling (marking) of cuts , holes, bending lines with s techn. engraved number of the drawing , notch
|
